Characteristics:
Built-in primary coil, strong overload capacity , used for over-current/under-current measurement,leakage current detection, current metering, powermonitoring, current feedback.
Technical index:
Mounting type：PCB
Material of the core：Silicon steel sheet
Flame resistance：UL94-V0
Execution standard：GB20840-2014
Operating temperature：-20℃～+70℃
Storage temperature：-30℃～+80℃
Frequency range：50Hz-60Hz
Dielectric strength：2.5KV 50Hz 1min
| Core Type | Solid-Core |
| Core material | Laminated silicon steel |
| Mounting Type | PCB |
| Rated Input | 5A |
| Output Type | AC |
| Rated Output | 20mA, 10mA, 5mA |
| Dielectric Strength | 2.5KV 50Hz 1min |
| Frequency Range | 50Hz - 60Hz |
| Connection Type | Pins |
