| Core Type | Core material | Mounting Type | Window Diameter | Rated Input | Output Type | Rated Output | Accuracy | Dielectric Strength | Frequency Range | Connection Type |
|---|---|---|---|---|---|---|---|---|---|---|
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | - | 50A, 100A, 200A | AC | 0.1A, 0.2A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | - | 200A, 400A | AC | 0.2A, 0.133A, 0.1A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | - | 600A, 800A | AC | 0.1A, 0.2A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Nanocrystalline | Free Hanging(In-Line) | Φ12.9mm | 30A, 45A, 60A, 100A | AC | 3.53V, 0.1A, 50mA, 33.3mA | 5KV 50Hz 1min | 20Hz - 20KHz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | Φ19mm | 50A, 100A, 200A, 300A | AC | 50mA, 80mA, 0.1A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | Φ20mm | 300A, 500A, 600A, 800A | AC | 0.3A, 0.25A, 0.2A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | Φ31.5mm | 200A, 400A | AC | 0.2A, 0.133A, 0.1A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable | |
| Solid-Core | Nanocrystalline | Free Hanging(In-Line) | Φ32mm | 200A, 300A, 500A, 600A | AC | 0.2A, 0.15A | 6KV 50Hz 1min | 20Hz - 20KHz | Cable | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | - | 500A, 600A, 700A | AC | 0.1A, 0.2A | 3.5KV 50Hz 1min | 50Hz - 60Hz | Welding piece | |
| Solid-Core | Laminated silicon steel | Free Hanging(In-Line) | - | 15A-75A | AC | 0.1A | 6KV 50Hz 1min | 50Hz - 60Hz | Cable |
