TRV03 - Input Range
- 100A~10000A
- Rated Output
- 0.333V, 1V, 3.3V
- Accuracy
- 1%
- Connection Type
- Screw Terminal
- Mounting Type
- Free Hanging(In-Line)
| Input Range | Rated Output | Accuracy | Connection Type | Mounting Type |
|---|---|---|---|---|
| 100A~10000A | 0.333V, 1V, 3.3V | 1% | Screw Terminal | Free Hanging(In-Line) |
| 100A~10000A | 0.333V, 1V, 5V | 1% | Screw Terminal | DIN-Rail |
| 100~10000A | 0.333V, 1V, 3.3V | 1% | Screw Terminal | Free Hanging(In-Line), Plate |
| ≤500KA | 50mV/KA@50Hz, 60mV/KA@60Hz | 0.5% | Cable | Free Hanging(In-Line), Plate |
| ≤500KA | 85mV/KA@50Hz 102mV/KA@60Hz, 100mV/KA@50Hz 120mV/KA@60Hz | 0.5% | Cable | Free Hanging(In-Line) |
| 30A~6KA | 1V AC, 1V DC | 0.5% | Cable | Free Hanging(In-Line), Plate |
| 100A~10000A | 50mA, 1A | 0.5% | Screw Terminal | DIN-Rail |
| 100A~10000A | 20mA,30mA,40mA,50mA,100mA,1A | 1% | Screw Terminal | DIN-Rail |
| 100A~10000A | 5A | 1% | Screw Terminal | Plate |
| 0~10000A | 5V | 2% | Screw Terminal | DIN-Rail |
| 100~10000A | 4-20mA, 0-5V, 0-1V, 0-10V | 1% | Screw Terminal | DIN-Rail |
| 100~10000A | 0-4V | 1% | Screw Terminal | Free Hanging(In-Line), Plate |
| 100~10000A | 4-20mA, 0-1V | 1% | Screw Terminal | DIN-Rail |
| 100~10000A | 4-20mA, 0-5V, 0-1V, 0-10V | 1% | Screw Terminal | Plate |
| 100~10000A | 0.333V, 1V, 5V | 1% | Screw Terminal | Plate |
TRV03
TRV02
TRV01
RFSY Rogowski Coil
RFSZ
RFIZ
TRA03
TRA05
TRA06
TRH02
TRS02
TRS01
TRS03
TRS04
TRV04
