Product features：
plate type installation, vacuum epoxy sealing, pressure connection terminal wiring.
Technical index：
Mounting type：Plate mounting
Flame resistance：UL94-V0
Insulation grade: B
Operating temperature：-35℃～+85℃
Storage temperature：-45℃～+95℃
Frequency range：50Hz-60Hz
Dielectric strength：3.5KV 50Hz 1min
| Core Type | Solid-Core |
| Core material | Laminated silicon steel |
| Mounting Type | PCB |
| Rated Input | 5A |
| Output Type | AC |
| Rated Output | 0.1A |
| Dielectric Strength | 3.5KV 50Hz 1min |
| Frequency Range | 50Hz - 60Hz |
| Connection Type | Screw Terminal |
